AIRBRAKE FITTINGS SERIES Manufacturers

Bulkhead Connectors With 24° Cone

Zhuji Xiangjia Machinery Co., Ltd. is professional China AIRBRAKE FITTINGS SERIES Manufacturers and OEM AIRBRAKE FITTINGS SERIES factory established in 2013, the company focuses on brass fittings, customized precision parts, we can provide economic and efficient machining solutions and quality products for customers' project needs, and achieve win-win situation with professional technology and processing ability. The company has passed the certificate: Xiangjia Machinery has passed the IATF 16949:2016 system certification, and is a professional manufacturer of brass fittings, AIR BRAKE HOSE ASSEMBLIES, stainless steel fittings, ISO 9001 & ISO 14001 system certification, DOT, AMECA product certification.

Get password

Latest News

Follow the latest news to get the latest market dynamics

Straight SAE Flare SMC DOT KV2...

Part# Tube*Thread UNF Hex L XJ2H-S4D 1/4*7/16-20 14.29 27.4 XJ2H-S6E 3/8*5/8-18 17.46 33 XJ2H-S8E 1/2*5/8-18 22.23 39.5 XJ2H-S8F 1/2*3/4-18 22.23 36.8

Sep, 03, 2024

View More
Compatibility of Brass Hose Ba...

The compatibility of brass hose barb fittings refers to their suitability for use with specific types of hoses and fluids. Several factors contribute to the compatibility of these ...

Jan, 08, 2024

View More
Compatibility of Brass Hose Ba...

The compatibility of brass hose barb fittings refers to their suitability for use with specific types of hoses and fluids. Several factors contribute to the compatibility of these ...

Jan, 08, 2024

View More
Can brass pipe fittings be use...

Brass pipe fittings can be used in a variety of environments, including corrosive ones, but the extent of their corrosion resistance depends on the specific alloy composition and ...

Jan, 01, 2024

View More

A	C	D	E	F	G	H	M	SW	SW1	Weight (g)
6001-6-M10X1R	6x1	6	M10X1	22	14.5	16	7*	22.5	14	25
6001- 6-M12X1.5R	6x1	8.2	M12X1.5	25	14.5	19	9	22.5	17	34
6001- 6-M16X1.5R	6x1	8.2	M16X1.5	26	14.5	24	9	23	22	46.5
6001- 6-M22X1.5R	6x1	8.2	M22X1.5	29	14.5	30	9	23	27	60
6001- 8-M10X1R	8x1	6	M10X1	23	16.5	16	7*	25	14	30.5
6001- 8-M12X1.5R	8x1	8.2	M12X1.5	26	16.5	19	9	25	17	39.5
6001 -8-M14X1.5R	8x1	8.2	M14X1.5	26	16.5	21	9	25	19	40
6001- 8-M16X1.5R	8x1	8.2	M16X15	26	16.5	24	9	25	22	45.5
6001- 8-M22X1.5R	8x1	8.2	M22X15	29	16.5	30	9	25	27	60
6001-10/7-M12X1.5R	10x1.5	8.2	M12X1.5	27	18.5	19	9	27	17	48
6001-10/7-M16X1.5R	10x1.5	8.2	M16X15	27.5	18.5	24	9	27	22	55.5
6001-10/7-M22X1.5R	10x1.5	8.2	M22X15	29	18.5	30	9	27	27	69.3
6001- 10-M12X1.5R	10x1	8.2	M12X1.5	27	18.5	19	9	27	17	47
6001- 10-M16X1.5R	10x1	8.2	M16X1.5	27.5	18.5	24	9	27	22	54
6001- 10-M22X1.5R	10x1	8.2	M22X1.5	29	18.5	30	9	27	27	68
6001- 12-M12X1.5R	12x1.5	8.2	M12X1.5	28.5	20.5	19	9	28.5	17	55.5
6001- 12-M16X1.5R	12x1.5	8.2	M16X1.5	28.5	20.5	24	9	28.5	22	59.5
6001- 12-M22X1.5R	12x1.5	8.2	M22X1.5	30	20.5	30	9	28.5	27	72.5
6001- 15/11-M16X1.5R*	15x2	8.2	M16X1.5	31.5	24.5	24	9	34	22	94
6001- 15/11-M22X1.5R*	15x2	8.2	M22X1.5	34	24.5	30	9	34	27	106
6001- 15-M16X1.5R	15x1.5	8.2	M16X1.5	31.5	24.5	24	9	34	22	91
6001- 15-M22X1.5R	15x1.5	8.2	M22X1.5	34	24.5	30	9	34	27	103
6001- 16/12-M16X1.5R	16x2	8.2	M16X1.5	33	25	24	9	35.5	22	114
6001- 16/12-M22X1.5R	16x2	8.2	M22X1.5	33	25	30	9	35.5	27	117.5
6001- 16-M22X1.5R	16x1.5	8.2	M22X1.5	33	25	30	9	35.5	27	117.5
6001- 18-M22X1.5R	18x2	8.2	M22X1.5	33	27.5	30	9	35.5	27	115

PART#	A	C	D	E	F	G	H	L	M	SW	SW1	Weight (g)
XJ9412 6-M10X1R	6x1	6	M10X1	23	14.5	16	7	45	22.5	9	14	38
XJ9412 6-M12X1.5R	6x1	8.2	M12X1.5	27.5	14.5	19	9	46	23	11	17	57
XJ9412 6-M16X1.5R*	6x1	8.2	M16X1.5	28	14.5	24	9	46	23	11	22	64.5
XJ9412 6-M22X1.5R	6x1	8.2	M22X1.5	32	14.5	30	9	49	24.5	15	27	87
XJ9412 8-M12X1.5R	8x1	8.2	M12X1.5	27.5	16.5	19	9	50	25	11	17	59.5
XJ9412 8-M16X1.5R	8x1	8.2	M16X1.5	28	17	24	9	50	25	11	22	67
XJ9412 8-M22X1.5R	8x1	8.2	M22X1.5	32	16.5	30	9	53	26.5	15	27	95.5
XJ9412 10/7-M12X1.5R*	10x1.5	8.2	M12X1.5	29	18.5	19	9	55	27.5	15	17	86
XJ9412 10/7-M16X1.5R*	10x1.5	8.2	M16X1.5	29	18.5	24	9	55	27.5	15	22	91
XJ9412 10/7-M22X1.5R*	10x1.5	8.2	M22X1.5	32	18.5	30	9	55	27.5	15	27	103
XJ9412 10-M12X1.5R	10x1	8.2	M12X1.5	29	18.5	19	9	55	27.5	15	17	83
XJ9412 10-M16X1.5R	10x1	8.2	M16X1.5	29	18.5	24	9	55	27.5	15	22	88
XJ9412 10-M22X1.5R	10x1	8.2	M22X1.5	32	18.5	30	9	55	27.5	15	27	100.5
XJ9412 12-M12X1.5R	12x1.5	8.2	M12X1.5	29	20.5	19	9	57	28.5	15	17	77
XJ9412 12-M16X1.5R*	12x1.5	8.2	M16X1.5	29	20.5	24	9	57	28.5	15	22	83
XJ9412 12-M22X1.5R	12x1.5	8.2	M22X1.5	32	20.5	30	9	57	28.5	15	27	95.5
XJ9412 15/11-M16X1.5R*	15x2	8.2	M16X1.5	33.5	24.5	24	9	68	34	18	22	135.5
XJ9412 15/11-M22X1.5R	15x2	8.2	M22X1.5	34	24.5	30	9	68	34	18	27	146.5
XJ9412 15-M16X1.5R	15x1.5	8.2	M16X1.5	33.5	24.5	24	9	68	34	18	22	129.5
XJ9412 15-M22X1.5R*	15x1.5	8.2	M22X1.5	34	24.5	30	9	68	34	18	27	140.5

Model	A	D	E	F	H(min）	M	SW	Weight(g)
6003 6-02	6x1	1/8 NPTF	17.5	14.5	8.5	21.5	9	18
60030 05-02	8x1	1/8 NPTF	17	16.5	7	25	11	23
60030 12-06	12x1.5	3/8 NPTF	24.5	20.5	10.5	28.5	15	46

Model	A	D	E	F	H	L	M	SW1	Weight(g)
6004 6-02	6x1	1/8 NPTF	17.5	14.5	7	45	22.5	9	30.5
6004 05-02*	8x1	1/8 NPTF	18	17	7	50	25	11	42

Model	A	D	F	G	H	L	SW	Weight(g)
6005 6-M10X1	6x1	M10X1	13.8	15	7	27.5	14	17.5
6005 6-M12X1,5R	6x1	M12X1,5	13.8	15	10	27.5	14	17.5
6005 6-M14X1,5R	6x1	M14X1,5	13.8	15	10	26.5	14	19.5
6005 6-M16X1,5R	6x1	M16X1,5	13.8	17	10	19.5	14	17.5
6005 8-M10X1	8x1	M10X1	16.5	18.5	7	30	17	26.5
6005 8-M12X1,5R	8x1	M12X1,5	16.5	18.5	10	32	17	28.5
6005 8-M14X1,5R	8x1	M14X1,5	16.5	18.5	10	29	17	26
6005 8-M16X1,5R	8x1	M16X1,5	16.5	18.5	10	28.5	17	29.5
6005 8-M22X1,5R	8x1	M22X1,5	16.5	23	10	21	19	39.5
6005 10/7-M12X1,5R	10x1,5	M12X1,5	17.8	19.5	10	33.5	18	26.5
6005 10/7-M16X1,5R	10x1,5	M16X1,5	17.8	19.5	10	29.5	18	29
6005 10/7-M22X1,5R	10x1,5	M22X1,5	18.5	23	10	22.5	19	37
6005 10-M12X1,5R	10x1	M12X1,5	17.8	19.5	10	33.5	18	26.5
6005 10-M16X1,5R	10x1	M16X1,5	17.8	19.5	10	29.5	18	29
6005 10-M18X1,5R*	10x1	M18X1,5	17.8	19.5	10	29.5	18	34
6005 10-M22X1,5R	10x1	M22X1,5	18.5	23	10	22.5	19	37
6005 12-M12X1,5R	12x1.5	M12X1,5	19.8	21.5	10	35.5	20	34
6005 12-M14X1,5R	12x1.5	M14X1,5	19.8	21.5	10	35	20	35.5
6005 12-M16X1,5R	12x1.5	M16X1,5	19.8	21.5	10	34	20	37
6005 12-M22X1,5R	12x1.5	M22X1,5	20.5	24	10	23	22	37
6005 15/11-M16X1,5R*	15x2	M16X1,5	23.8	26.5	10	39	24	53.5
6005 15/11-M22X1,5R*	15x2	M22X1,5	23.8	26.5	10	32	24	50.5
6005 15-M16X1,5R	15x1.5	M16X1,5	23.8	26.5	10	39	24	53.5
6005 15-M22X1,5R	15x1.5	M22X1,5	23.8	26.5	10	32	24	50.5
6005 16/12-M16X1,5R	16x2	M16X1,5	25	30	10	42.5	27	75
6005 16/12-M22X1,5R	16x2	M22X1,5	25	30	10	35	27	68.5
6005 16-M22X1,5R	16x1.5	M22X1,5	25	30	10	35	27	68.5
6005 18-M22X1,5R	18x2	M22X1,5	26.8	30	10	40	27	68

China Brass Fittings Manufacturers, Compression, Push On Fittings Suppliers

Web Menu

Product Search

Language

Exit Menu

AIRBRAKE FITTINGS SERIES Wholesale

PRODUCT

contact us

AIRBRAKE FITTINGS SERIES Manufacturers

Shaped Non-Swivel Connectors

Swivel Tee fittings Mod

Elbow Fittings

Tee Fittings

Straight Fittings

Fittings With Female Thread

Straight Fittings

Bulkhead Connectors

Bulkhead Connectors With 24° Cone

Bulkhead Connectors

Connectors

Tee Fittings

Latest News

Straight SAE Flare SMC DOT KV2...

Compatibility of Brass Hose Ba...

Compatibility of Brass Hose Ba...

Can brass pipe fittings be use...

Industry Knowledge Extension

contact us

QUICK LINKS

Feedback

Mobile terminal

Model	A	D	F	G	H	h	L	N	T	Y	Z	SW	SW1	Weight(g)
6008 8-M18X1,5	8x1	M18X1,5	/	25.5	50	10	55.5	10.8	15.7	53	4	22	22	99.5
6008 12-M18X1,5	12x1,5	M18X1,5	20.5	25.5	34	4	53	11	16	60	5	22	22	83
6008 12-M18X1,5-S04	12x1,5	M18X1,5	20.5	25.5	33	4	52	10.8	15.7	53	4	22	/	71

Model	A	B	D	F	G	H	h	L	SW	Weight(g)
6009 6-M14x1,5	6x1	8	M14X1,5	14.5	20	21	2.5	36	17	36
6009 8-M14x1,5	8x1	8	M14X1,5	16.5	20	21	2.5	43.5	17	46
6009 8-M16x1,5	8x1	10	M16X1,5	16.5	22	21	2.5	37	19	44
6009 12-M18x1,5-S06	12x1,5	12	M18X1,5	20.5	25.5	21	2.5	40	22	56

Model	A	B	C	C1	D	F	G	G1	H	h	L	SW	SW1	Weight(g)
6010 6-6-M18X1,5	6x1	6x1	6	7	M18X1,5	14.5	23	25.5	9	2.5	37.5	20	22	64
6010 8-8-M18X1	8x1	8x1	5.5	7	M18X1		25.5	25.5	30	18	43.5	22	22	77
6010 8-8-M20X1,5	8x1	8X1	6	5	M20X1,5	18.5	25.5	27.5	11	2.5	41	22	24	82
6010 12-8-M18X1	12x1.5	8/6	7.5	7	M18X1	20.5	25.5	25.5	30	18	57	22	22	90.5
6010 12-12-M24X1,5	12x1.5	12X1.5	7.5	6	M24X1,5	20.5	31	31	10	2.5	46	27	28	113
6010 15-15-M28X1,5	15x1.5	12X1.5	7	6	M28X1,5	25	34.5	34.5	13	2.5	52	30	32	158

Model	A	F	L	Weight(g)
6011 6	6x1	14	27.5	21
6011 8	8x1	16	41	27
6011 10/7	10x1.5	18	44	34
6011 10	10x1	18	44	33
6011 12	12x1.5	20	45.5	43
6011 15/11	15x2	24	52	87
6011 15	15x1.5	24	52	87
6011 16/12	16x2	25	58	100
6011 18	18x2	27	57	109
